Starting with the Business edition of CardExchange® Visitor, you can also choose to use the Network License Setup, this allows for concurrent licensing and the ability to run a CardExchange® client on a server operating system.
This would typically have the license manager installed on a server along with the database and configuration. The network client is then installed on the workstations that will be using the software.
For installing a CardExchange® Network License editions, the following operating systems are supported:
•Windows 7, Windows 8, Windows 10
•Windows Server 2008 R2, 2012
•Citrix and Terminal Systems
•Virtual Machines
All operating systems are supported as 32 and 64 bit systems and need to run the latest available service packs of Microsoft.
For running CardExchange® Network editions on servers or workstations we advice the following minimum specifications:
•400 MB free disk space for Workstations
•Dual core processor
•2048 MB internal memory (32bit)
•4096 MB internal memory (64bit)
•Microsoft .NET Framework 4.8
Specific Firewall information:
Firewall issues are usually solved by adding the Sentinel RMS License Manager to your the firewall exceptions. The provider of the licensing system SafeNet states that:
"The Sentinel RMS License Manager only uses the UDP port 5093 at Server end by default. And at client end the ports are used dynamically and controlled by Operating System i.e. for communication only UDP port 5093 is used at server end and at client end it is used dynamically on the basis of available port."
